Motion Control – One Piece ETX Linear Bearing/Pillow Blocks Can Be Used In Radioactive Environments

Posted by Editor on October 19th, 2022

Motion Control- ETX Linear Bearing/Pillow Blocks

E. Longmeadow, MA Motion — Control Components – Linear Motion – LM76 now offers one piece ETX Linear Bearing/Pillow Blocks that will not degrade in a radioactive environment! Machined from a solid block of self lubricating ETX, linear bearing-blocks have high strength, excellent wear resistance, low coefficient of friction, and excellent dimensional stability at higher temperatures as there is no other materials such as PTFE seals or lubricants these bearing-blocks are maintenance free.

Custom designed for use in a nuclear power plant these linear bearing/pillow blocks travel on ceramic coated shafting (also supplied by LM76) completely submerged in radioactive water.

To see the “Motion Control Application – ETX Pillow/Block Bearings for Radioactive Environments” CLICK HERE

Motion Control – Linear Focus Actuator from Equipment Solutions Features 200 Nano Meters Repeatability!

Posted by Editor on October 17th, 2022

Motion Control – 200 Nano Meters Repeatability Actuator!

Forestville, CA, – — Motion Control – This LFA-0604 Linear Focus Actuator: Flexture guidance system, 6 millimeter clear aperture, 4 millimeters of linear motion, 90 G’s acceleration (no load), 200 nanometers positioning repeatability, non-contact electro-optic position sensor, direct SCA814 Servo Controlled Amplifier compatibility, 38mm x 24mm, 80 grams

Motion Control Application – Lab automation is getting even smaller

Posted by Editor on October 15th, 2022

Motion Control Application – Lab Automation

Motion Control Application – When you need the accuracy but don’t have the room or the budget.

Fall River, MA – Motion Control Application – UK Robotics has recently launched a new liquid handler to shake up the lab automation market. Feedback from small biotech companies and big pharmaceuticals has been beyond the company’s wildest expectations.

The Bolton based company specializes in building integrated systems for lab automation for life sciences. They have now used their 15 years of experience in the industry to create a new two valve nanolitre microplate reagent dispenser.>/span>

Motion Control Components – Maxon’s New IDX Integrated Servo Motor – Power at the Press of a Button!

Posted by Editor on October 13th, 2022

Motion Control – Integrated Servo Motor

This compact brushless EC-i motor combined with an EPOS4 positioning controller delivers a highly dynamic, powerful drive package with field-oriented control (FOC), high efficiency, and maintenance-free components in a high-quality industrial housing.

Vaughan, Ontario, Canada — Motion Control Components — Maxon’s new IDX compact integrated servo gearmotor + drive combines a powerful, brushless EC-i motor and an EPOS4 positioning controller, which can be complemented with a maxon planetary gearhead when required. This integrated motor stands out for its high torque density, high efficiency, maintenance-free components, and a high-quality industrial housing providing IP65 protection.

Motion Control – Low Cost, High Precision Linear Voice Coil Stages from Moticont!

Posted by Editor on October 11th, 2022

Motion Control – Voice -Coil Stage

Van Nuys, CA – Motion Control – Components -– Moticont’s VCDS-051-089-01 series linear motion control voice coil stages feature a voice coil motor, a ball bearing linear slide, home switch, and an integral optical quadrature encoder with differential outputs. Measuring 13.5 in (342.9 mm) long x 4.00 in. (101.6) wide x 3.755 in. (95.4 mm) high, the VCDS-051-089-01 series stages have a linear travel of 2.20 in. (55.9 mm); a continuous force of 6.0 lbs (26.7 N) and a peak force of 19 lbs (84.3 N) (at a 10% duty cycle).

Motion Control – NEW! Elevator Stages from OES Feature 0.03 micron Resolution!

Posted by Editor on October 8th, 2022

Motion Control – 0.03 micron Resolution Elevator Stage!

motion control - elevator stage

Van Nuys, CA – — Motion Control – Two new motorized elevator stages, the DAG20-120-01 and the DAG20-120-04 have been released by Optimal Engineering Systems, Inc. (OES). These high resolution, compact, low profile elevator stages feature high stability 120 mm x 120 mm tables and 20 mm of vertical travel. High precision ball bearing profile rails assure very high parallelism and smooth motion throughout the raising and lowering of the table. These Z-Axis Stages are ideal for: Microscopy, inspection, metrology, positioning, photonics, sampling, and laser drilling and machining.

Motion Control – Linear Bearings – Which Type is Right for Your Application?

Posted by Editor on October 6th, 2022

Motion Control – Linear Bearings – Comparison: Ceramic Coated vs Linear Ball Bearings

Motion Control – Application – maxon drives are used in the rover and in the first Mars helicopter

Posted by Editor on October 2nd, 2022

Motion Control – Application – Maxon Goes to Mars!

The Helicopter is Still Flying …

… 28 Trips and Counting!

Taunton, MA — Motion Control – Application – DC motors from maxon have been used in virtually all successful robot missions on Mars. More than 100 of these drives from Switzerland are already on the Red Planet and the number will go up again when the Perseverance rover starts its work. Its mission is to collect soil samples on Mars that will be analyzed on Earth later. The rover also carried the Ingenuity helicopter drone, which will be performing the first flights on the Red Planet. maxon’s precision motors and gearheads are used in numerous mission-critical tasks.

Motion Control – 20 mm Linear Stepper Motor by Nippon Pulse are available from Electromate!

Posted by Editor on September 30th, 2022

Motion Control – 20 mm Linear Stepper Motor!

Vaughan, Ontario, Canada — Motion Control — Nippon Pulse is excited to introduce its smallest linear stepper motor yet, the PFL20 Linearstep. The PFL20 is a highly efficient, high thrust tin-can linear actuator with a 20mm diameter and a bipolar winding.

The motion control PFL20 is RoHS-compliant, has a 30/60mm effective stroke, and can reach 6 N of force at 200 pps. With 24 steps per revolution, the lead screw has a 1.2mm thread pitch; the PFL20 also reaches 5V rated voltage, resistance of 33 Ohms/phase and inductance of 12mH/phase. The datasheet with additional specifications can be found here.

Motion Control – Compact 0.750 Inch Diameter Voice Coil Motor Features A 1.500 Inch Stroke and High Force-to-Size Ratio!

Posted by Editor on September 28th, 2022

Motion Control – Long Stroke Voice Coil Motor!

Van Nuys, CA — Motion Control – Moticont has added a 0.750 in. (19.1 mm) diameter (smaller than a US Quarter) Linear Voice Coil Motor, to their expanding line of voice coil or moving coil motors. The LVCM-019-048-02 Linear Voice Coil Motor is a true servo motor featuring zero cogging, high accuracy, and high repeatability when operated in a closed position loop. Voice Coil Motors (also referred to as actuators) are clean, quiet, efficient, brushless high speed linear servo motors.

This small LVCM-019-048-02 diameter actuator has a 1.500 in (38.1 mm) stroke length and a high-force-to-size ratio of 7.4 oz (2.1 N) and a peak force of 23.5 oz. (6.5 N) at 10% duty cycle.

Motion Control – High Precision 300 MM Motorized Vertical Lift Stage from OES Features: Stability, High Load Capability, and Low Cost!

Posted by Editor on September 24th, 2022

Motion Control – Vertical Lift Stage

Van Nuys, CA – — Motion Control – A vertical lift of 300 mm (11.811 in.), high stability, and low cost are just some of the features of the AT20-300 Motorized Vertical Lift Stage from Optimal Engineering Systems, Inc. (OES). This high load, 50 kg (110.2 lbs), vertical lift stage can be easily integrated into almost any application. The large 400 mm x 200 mm (15.748 in. x 7.874 in.) stage has a pattern of threaded mounting holes. The rigid box construction of the moving component of the elevator stage travels on six slide rails assuring smooth vertical travel and parallelism of the table and mounting surface at all times, and features: 3.315 µ (non- Micro-Step) resolution, 5 µ repeatability, and 15 µ positional accuracy.

Motion Control – Linear Stage Features Sub-micron Positioning, 10 mm Clear Aperture, and High Acceleration!

Posted by Editor on September 20th, 2022

Motion Control – Sub-micron Positioning Linear Stage!

Forestville, CA – Motion Control Components – Equipment Solutions’ Series of VCS-10 Voice Coil Stages feature: Sub-micron positioning, high acceleration, digital and/or analog position sensors, and are available with a 10 mm clear aperture! These high acceleration stages (50 G’s no load), have 10 mm of linear motion and < 3 millisecond step response time. The customizable VCS-10 Series of linear position stages are ideal for high speed, high precision optical and laser focusing applications in: Medical, semiconductor inspection and manufacturing, scanning microscopy, and micro machining/manufacturing.

Motion Control – Maxon’s Driven Magazine – See the article “Speed or Torque – or Both?”

Posted by Editor on September 18th, 2022

Motion Control – Maxon’s Driven Magazine

Motion Control article “Speed or Torque – or Both” in Maxon’s Driven magazine helps in selecting the right motor for an application. An application that could be on Mars, under water, or even implanted in the human body!

Fall River, MA — Motion Control – The Maxon catalog contains a large number of brushless motor types that are called EC Motors. The artice in this issue of DRIVEN briefly describes their properties and possible areas of application.

Motion Control – ADVANCED Motion Controls 60Amp Micro-Sized FlexPro Servo Drives are available from Electromate!

Posted by Editor on September 16th, 2022

Motion Control – Micro-Sized Servo Drives!

Vaughan, Ontario, Canada — Motion Control — ADVANCED Motion Controls has released 7 new micro-sized FlexPro servo drives rated to output 60A continuous. The 60A continuous current rating is 33% higher than previous models for the same size making these our highest power-density servo drives to date. This offering includes PCB Mount, Machine Embedded, and Development Board-factors.

Motion Control – Direct Drive Linear Motor Has Integrated Encoder and Temperature Sensor for Increased Throughput!

Posted by Editor on September 14th, 2022

Motion Control – Linear Actuator Gives Higher Throughput!

Van Nuys, CA – Motion Control Products – The new patented SDLM-019-070-01-01 direct drive linear motor with integrated position and temperature sensors is the latest addition to the series of zero backlash, zero cogging, high acceleration, high speed, high resolution, long life motors from Moticont. Also known as an electric cylinder, this compact direct drive linear motor is just 0.75 in. (19.1 mm) in diameter and 2.75 in (69.9 mm) long. Protected inside the motor housing, the linear optical quadrature encoder is directly connected to the shaft for the greatest possible accuracy. Highest throughputs are achieved by the SDLM-019-070-01-01 linear motor when operating at peak efficiency monitoring the data from the internal temperature sensor.

Motion Control – Choose the Right, High Precision, Low Cost Linear Stage to Suit Your Motion Control Application!

Posted by Editor on September 9th, 2022

Motion Control – High Precision Linear Stages

Van Nuys, CA – — Motion Control Components – OES (Optimal Engineering Systems) offers ten high precision, low cost linear positioning stages that can be easily integrated into new and existing applications. Choosing the best slide for the application is easy. The five AQ120 and five AQ130 series of linear motorized stages are available in travel distances of: 50 mm (1.969 in.), 100 mm (3.937 in.), 150 mm (5.906 in.), 200 mm (7.874 in.), and 300 mm (11.811 in.).

Motion Control – Linear Motion – How Do You Move Articles of Antiquity?

Posted by Editor on September 6th, 2022

Motion Control – Linear Bearings Application

Motion Control Application – How Do You Move Articles of Antiquity?

“Very Carefully” With A High Load Rail System from LM76!

E. Longmeadow, MA – — Motion Control – Application -The Boston Museum of Fine Arts (MFA) has to move articles of antiquity from one location to another. In this instance, they are moving a 5000 year old relief (hieroglyphics) weighing 8000 pounds to a new location in the Museum. Here is a frontal photo of the Relief from The Tomb of Senenuka.

Part of wall from tomb of Senenuka; nine stones fitting together and including two niches; lower left piece smooth limestone; upper far left preliminary black ink sketch; right of this sketch is a complete relief showing two seated figures; central piece has large scene of seated male on the left and other smaller male figure to the right; upper far right male figure relief outline; left of this again a scene of two seated figures at a table.

Senenuka Time of Khufu or Khafre (Maybe Dyn 5?) Overseer of the Pyramid-town of Khufu, Director of King’s wad-priests, Boundary official of a settlement, etc.

Motion Control – Servo Controller for Non-comutated Devices, e.g. voice coil motors, from Equipment Solutions!

Posted by Editor on September 3rd, 2022

Motion Control – Servo Controller for Non-comutated Devices!

Motion Control – SCA601 Linear Servo Controller: High Performance analog PID Servo Control law; Digital control of PID tuning parameters; Analog Position Sensor input; High current linear amplifier; RS232 interface; 76 x 76 x 25

Forestville, CA, – Motion Control — The SCA601 Linear Servo Controller was specifically designed to control single phase, non-comutated devices like voice coil motors. It is a high performance single axis DC motor controller and amplifier system. It is comprised of a highly integrated single PC board level product with a cohesive interface and a compact heat sink.

Motion Control – Frameless BLDC motor with matching encoder for a wide range of robotics applications!

Posted by Editor on August 31st, 2022

Motion Control – Frameless BLDC Motor

Taunton, MA — Motion Control Products – maxon presents a new frameless BLDC motor with matching encoder that really comes into its own in dynamic applications. This heralds the arrival on the market of several solutions for design engineers grappling with tight spaces.

Innovative motor concepts are the answer to growing market requirements for dynamic response, compactness, and power density. With the EC frameless DT, maxon presents a solution that really packs a punch. The DT50 is the precursor of a new product family developed specifically for dynamic movements. The brushless motor with its frameless concept can be easily integrated into a wide range of applications by design engineers.

Motion Control – Large Hollow Shaft Harmonic Drive Gear Unit Available from Electromate!

Posted by Editor on August 28th, 2022

Motion Control – Hollow Shaft Harmonic Drive Gear Unit

Vaughan, Ontario, Canada — Motion Control Components — The new FBS-2UH gear unit series from Harmonic Drive® features a large, hollow shaft with a compact outer diameter. The extra large hollow shaft is ideal for robots and machines requiring complex cabling to pass through the axis of rotation.

The new gear unit design features Harmonic Drive’s “S” tooth profile for optimal tooth engagement resulting in high torque, high-torsional stiffness, long life and smooth rotation.

The FBS-2UH Series is available in two sizes (25, 32) and three ratios (30:1, 50:1, and 100:1).

Key features include:

Extra large hollow-shaft diameter is our largest yet for a standard product
Compact dimensions for use in robotics
Outer diameter and hollow bore optimized for design flexibility and performance
Zero Backlash
Accuracy <1 arc-min
High torsional stiffness
High efficiency
Smooth operation

CLICK HERE for information on the FBS-2UH hollow-shaft gear unit.

About Electromate:

Electromate’s Core Purpose is to help Manufacturers build better machines using differentiated automation technology. They specialize in Robotic and Mechatronic Solutions for the Industrial Automation marketplace. Respected by customers as a premiere source for High Performance Automation and Motion Control Components & Systems, Electromate® specializes in AC & DC Servo and Stepper Motors & Drives, Motion & Automation Controllers, Positioning Systems & Actuators, Feedback Devices, Gearing Products and HMI’s & Operator Displays, all supported via extensive product selection, just-in-timedelivery, dedicated customer service and technical engineering support.
